San Antonio Gate Pros provides professional cantilever gates in San Antonio, TX for residential and commercial properties across the San Antonio area. Cantilever gates are the standard answer for the wide entries around San Antonio: ranch drives, acreage lots, contractor yards and anywhere a thirty-foot opening has to clear in one movement. The gate hangs from roller trucks on posts to one side and nothing touches the ground across the opening.
That last point is why the design suits this county. A slide gate on a track needs concrete running the full travel distance, and on limestone that means cutting a trench the whole length rather than digging one. A cantilever needs foundations only where its posts land, so the excavation is a fixed number of cored holes instead of a continuous rock cut. On a long opening the difference is substantial.
The trade is runback. The tail section behind the posts has to be long enough to counterbalance the span reaching out over the driveway, generally around half the opening width again. Big lots have that room, which is exactly why the design fits ranch entries and fits poorly on a tight suburban apron. Short-tailing a gate to make it fit loads the rear truck badly and shortens the life of everything.
We set posts on grouted rock sockets or on rock-bearing pads depending on what the test holes find, string-line them into plane, and mount roller trucks on deliberate shim packs so a later adjustment is a matter of plates rather than cutting welds in your driveway. Posts anchored into limestone stay in plane, which is the main advantage of building this design here. Runback is the first thing we measure on any wide entry.
Truck-rated versions get heavier tube, larger wheels and closer post spacing. A loaded trailer clipping a residential-grade frame ends that frame, and the difference in specification shows up in year three rather than in the first quote. That stability is what makes a cantilever worth its higher post count here. Once the sockets are cut and grouted, the geometry is settled and the remaining service is wear rather than correction.
There is a case against cantilever out here and it is worth stating. Four cored sockets on a lot where refusal comes at six feet of caliche rather than solid rock means four foundations that all need widening into bearing pads, and at that point a pair of swing leaves with two foundations is cheaper and simpler. The design wins on wide openings in good rock. It loses on wide openings in bad ground.
Service is measurement. Truck loading, tail droop, wheel and bearing wear, and the operator's force settings checked against the current geometry. On a rock-set gate that is an annual visit, not a recurring correction. Wheels, bearings and the tail droop are the items that actually consume life on this design, and all three are cheap to replace on schedule. We would rather sell you a visit than a frame.
With 15+ years of experience, our insured team brings the right materials and equipment to every job — wrought iron and ornamental steel fabrication, ranch entry gates and pipe fencing, truck-rated cantilever slide gates, LiftMaster, DoorKing and FAAC operators, Class I-IV operator classifications, UL 325 entrapment protection — and backs the work with a written workmanship warranty. We serve San Antonio and nearby communities including Alamo Heights, Schertz, Converse, Universal City.
What We Handle
Everything our cantilever gates in San Antonio covers
One crew, one point of contact, and the full range of cantilever gates work in San Antonio, TX. If it is on this list we do it in house rather than handing it to a subcontractor:
- cantilever slide gates
- cantilever gate installation
- truck-rated cantilever gates
- cantilever roller replacement
- commercial cantilever gates
- no-track slide gates
- industrial slide gates
- cantilever gate counterbalance
- cantilever gate repair
- cantilever gate back-run layout
- cantilever tail straightening
Not sure which one describes your situation? Describe it in plain words and we will sort it out — or browse the rest of our San Antonio services.
Materials, equipment and how we do cantilever gates
The difference between cantilever gates that lasts and cantilever gates that gets redone in three years is almost always preparation and materials, not the finish you see on day one. We work with wrought iron and ornamental steel fabrication, ranch entry gates and pipe fencing, truck-rated cantilever slide gates, LiftMaster, DoorKing and FAAC operators, spec them to the job instead of to the invoice, and write the material grades into the free estimate so you know exactly what you are buying.
Every San Antonio job runs the same way: site walk and measurements, written scope and fixed price, protection of the surrounding area, then the work itself with a daily clean-up. 15+ years of gate work in the San Antonio area means we have already met whatever your property is going to throw at us — awkward access, older construction, an HOA with opinions.
Where we do cantilever gates outside San Antonio
San Antonio Gate Pros covers San Antonio and the surrounding communities of the San Antonio area. Crews run out to the same nearby cities every week, so an out-of-town job does not mean an out-of-town price.
- Cantilever Gates in Alamo Heights, TX — Bexar County, population 8,400
- Cantilever Gates in Schertz, TX — Guadalupe, Comal and Bexar Counties, population 45,000
- Cantilever Gates in Converse, TX — Bexar County, population 28,000
- Cantilever Gates in Universal City, TX — Bexar County, population 20,000
- Cantilever Gates in Boerne, TX — Kendall County, population 20,000
- Cantilever Gates in Helotes, TX — Bexar County, population 10,000
Start on the San Antonio Gate Pros homepage for a free estimate, or call (877) 583-3964 and describe the job.
Why San Antonio Chooses San Antonio Gate Pros
- ✓Over 15 years installing and servicing gates across Bexar County and the Hill Country
- ✓In-house metal shop — we weld and powder coat our own gates rather than reselling panels
- ✓Footings sized to your actual soil, clay on the south side or limestone north of 1604
- ✓Every operator wired to UL 325 with photo eyes, loop detectors and tested entrapment protection
The standards behind cantilever gates
Quality here is not a matter of opinion — it is written down. The cantilever gates work we do in San Antonio follows published industry standards: DASMA is the standards body for door and access systems, and UL Solutions publishes UL 325, the safety standard for automatic gate operators. If a contractor cannot tell you which standard a detail comes from, that is worth asking about before you sign.
Every cantilever gates project in San Antonio gets the same attention, whether it is a single room or a full commercial job. We show up on schedule, keep the site clean, and stand behind the work — the estimate is free and there is no pressure.
Ready to get started? Call (877) 583-3964 for a free cantilever gates free estimate in San Antonio, or request a quote and we'll get right back to you.
